Quantek Q42 RACKMOUNT ANALYZERS
Test for O2 and CO2 levels in variety of applications
The Q40 series of analyzers feature a color display, menu driven setup, calibration functions, a built-in
sample pump, and data collection (up to 100,000 values).
This analyzer combines fast response sensors in a 2U rackmount form for use in all types of gas
measurement applications. It is powered by an AC to 12 Volt DC wall adapter.
The analyzer can be equipped with a rugged miniature diaphragm pump with adjustable timing functions
to operate only when sampling.
The Q40 Series is available with several sampling inlet configurations to suit many different monitoring
applications.
Swagelok compression fittings, a traditional sample probe, or lure fittings with flexible tubing
are all options. Unless otherwise specified, the inlet and outlet are located on the rear of the rackmount
analyzer for ease of access.
APPLICATIONS
The Q40 Series is equipped with fast response sensors, and is ideal for many different types of applications
including: Inert Gas Systems,Pre-gas check in MAP food packaging,Research, Oil and Gas Industry,
Carbon Capture,Reactors,Process Applications,Controlled atmosphere rooms Gas blending
Also it has a sampling pump, data collection, utilize electrochemical O2 and CO2 sensor,
sample fitting actions, and microprocessor of electronics.
